Brand Name : SUNCAR
Model Number : SPGW-60 Piston Seal
CertifiC-A-Tion : ISO9001
Place of Origin : CN
MOQ : 100 sets
Price : Negotiable
Payment Terms : L/C, D/A, D/P, T/T, Western Union,
Supply Ability : 550 Sets Per Week.
Delivery Time : 3-7 days after payment received(Public Holiday Excluded)
Packaging Details : PP bag inside,carton box outside.
Feature : Durability,hard-wearing,higher-toughness
MOQ : 100 Pcs
Transport : By air, by sea, by express ( FedEx , UPS,DHL,TNT etc.)
Brand : SUNCAR
Material : PA
Type : Hydraulic Piston seal
AppliC-A-Tion : hydraulic cylinder, automatic transmission devices, Hydraulic Shaft, Heavy Duty Tasks, Pneumatic cylinder
Color : Standard color/As per customer required
Keyword : Mechanical Parts Hydraulic Cylinder Piston Rod, Hard Chrome Plated Piston Rod, chrome hydraulic cylinder rod
Com,patible equipment : Komatsu
Hard Wearing Hydraulic Systerm SPGW-60 Piston Seal
SPGW piston seal is designed to be used in a variety of equipment and is particularly suited to use in earthmoving and other off-highway equipment.
Some Sizes Of SPGW For Your Reference:
ID | OD | H |
50 | 36 | 8.5 |
55 | 41 | 8.5 |
60 | 46 | 8.5 |
65 | 50 | 10.5 |
70 | 55 | 10.5 |
75 | 60 | 10.5 |
80 | 65 | 10.5 |
85 | 70 | 10.5 |
90 | 75 | 10.5 |
95 | 80 | 10.5 |
100 | 85 | 12 |
105 | 90 | 12 |
110 | 95 | 12 |
115 | 100 | 12 |
120 | 105 | 12 |
195 | 172 | 15.5 |
200 | 177 | 15.5 |
205 | 182 | 15.5 |
210 | 187 | 15.5 |
215 | 192 | 15.5 |
220 | 197 | 15.5 |
225 | 202 | 15.5 |
230 | 207 | 15.5 |
230 | 210 | 15.5 |
120 | 105 | 12 |
125 | 102 | 15.5 |
130 | 107 | 15.5 |
135 | 112 | 15.5 |
185 | 162 | 15.5 |
140 | 117 | 15.5 |
145 | 122 | 15.5 |
150 | 127 | 15.5 |
155 | 132 | 15.5 |
160 | 137 | 15.5 |
165 | 142 | 15.5 |
170 | 147 | 15.5 |
175 | 152 | 15.5 |
180 | 157 | 15.5 |
190 | 167 | 15.5 |
240 | 217 | 15.5 |
250 | 222 | 17 |
260 | 232 | 17 |
270 | 242 | 17 |
280 | 252 | 17 |
290 | 262 | 17 |
300 | 272 | 17 |
310 | 282 | 17 |
320 | 292 | 17 |
Data:
Material | Power-transmission fluid | Temperature | Speed | Pressure | Max. Gap F |
PTFE+bronze | Mineral Oil | -40 – +110 | ≦ 1.5 m/s | 160 bar | F ≦ 1.0 mm |
250 bar | F ≦ 0.8 mm | ||||
400 abr | F ≦ 0.6 mm | ||||
500 bar | F ≦ 0.4 mm |
Chamfers & Rod (mm) | Tolerance | Surface Finishing | ||||||
μm Ra | μm Rt | |||||||
S ≦ | 7 | 7.5 | 11.5 | 14 | ØD1 | H9 | 0.1-0.4 | ≦ 4 |
C ≧ | 4 | 4 | 6 | 7.5 | Ød1 | +0 -0.2 | ≦ 1.6 | ≦ 10 |
r1 ≧ | 1.6 | 1.6 | 1.6 | 1.6 | L | +0.2 -0 | ≦ 3.2 | ≦ 16 |
GS0535V5 | 707-44-50180 | 707-44-50080 | GS0813V5 |
GS0535V5 | 707-44-50080 | 707-44-50180 | GS0609V5 |
707-44-55080 | 707-44-55180 | 707-44-55180 | GS0609V5 |
707-44-55080 | 707-44-60180 | 707-44-60070 | GS0481V5 |
GS0528V5 | 707-44-60080 | 707-44-60070 | GS0481V5 |
GS0528V5 | 707-44-60080 | 707-44-60180 | GS0610V6 |
GS3013V5 | 707-44-65080 | 707-44-65180 | GS0610V6 |
GS3013V5 | 707-44-65080 | 707-44-65180 | GS0973V5 |
GS0607V5 | 707-44-70080 | 707-44-70180 | GS0973V5 |
GS0607V5 | 707-44-70080 | 707-44-70180 | GS0611V5 |
GS0995V5 | 707-44-75180 | 707-44-75180 | GS0611V5 |
GS0995V5 | 707-44-80180 | 707-44-80180 | GS0626V5 |
GS0608V5 | 707-44-85180 | 707-44-85180 | GS0626V5 |
GS0608V5 | 707-44-90180 | 707-44-90180 | GS0908V5 |
GS0813V5 | 707-44-95180 | 707-44-95180 | GS0908V5 |
GS0612V7 | 707-44-13080 | 707-44-13180 | GS0432V5 |
GS0612V7 | 707-44-13280 | 707-44-13280 | GS0432V5 |
GS0583V5 | 707-44-14080 | 707-44-14180 | 707-44-15080 |
GS0583V5 | 707-44-14180 | 707-44-14080 | 707-44-16080 |
GS0613V5 | GS0432V5 | 707-44-14180 | 707-44-16180 |
GS0613V5 | GS0907V1 | 707-44-14280 | E5130370 |
E5130380 | 707-44-16280 | 707-44-17180 | E5130370 |
707-44-17180 | GS0688V5 | 707-44-17080 | Y420-190000 |
707-44-18180 | GS0688V5 | 707-44-17080 | 707-44-19180 |
707-44-18280 | 707-44-17280 | 707-44-18180 | GS0616V5 |
GS0644V5 | 707-44-20180 | 707-44-19180 | Y420-190000 |
707-44-19280 | 707-44-22180 | 707-44-20180 | 707-44-21180 |
707-44-19280 | 707-44-22180 | 707-44-22080 | 707-44-22280 |
GS0617V5 | 707-44-23180 | 707-44-24180 | 707-44-24180 |
GS0617V5 | 707-44-28180 | 707-44-27180 | 707-44-27180 |
707-44-20280 | 707-44-28180 | 707-44-30180 | 707-44-30180 |
707-44-20280 | 707-44-21280 | GS0655V2 | GS0664V2 |
GS0654V2 | 707-44-21280 | GS0618V2 | VOE11088490 |
GS0654V2 | GS0655V2 | GS0618V2 | GS0656V2 |
GS0605V2 | GS0690V2 | GS0664V2 | GS0656V2 |
GS0605V2 | GS0690V2 | 707-44-15080 | GS0451V4 |
707-44-10180 | 707-44-10080 | 707-44-25180 | 707-44-25180 |
707-44-10180 | 707-44-10080 | 707-44-26180 | 707-44-26180 |
707-44-10280 | 707-44-10280 | 707-44-29180 | 707-44-32180 |
4161280 | 416-1280 | 707-44-29180 | GS0689V2 |
707-44-11180 | 707-44-11080 | GS0510V2 | GS0689V2 |
4161280 | 707-44-11150 | GS0510V2 | GS0619V2 |
416-1280 | 707-44-11180 | 707-44-31180 | GS0619V2 |
707-44-11080 | 707-44-11150 | 707-44-31180 | GS0451V4 |
707-44-11280 | 707-44-11280 | 707-44-16080 | GS0615V5 |
707-44-12180 | 707-44-12080 | E5130380 | 707-44-16280 |
707-44-12180 | 707-44-12080 | 707-44-18280 | 707-44-17280 |
707-44-12280 | 707-44-12280 | GS0653V5 | GS0616V5 |
707-44-13180 | 707-44-13080 | GS0644V5 | GS0653V5 |
707-44-14280 | GS0907V1 | 707-44-15180 | 707-44-32180 |
E5130340 | GS0614V5 | 707-44-22080 | 707-44-21180 |
707-44-15180 | GS0614V5 | 707-44-23180 | 707-44-22280 |
E5130340 | 707-44-15280 | 707-44-16180 | GS0615V5 |
707-44-16180 | 707-44-15280 | 707-44-16080 | GS0615V5 |
Installation:
The performance of profile KS piston seal set is only guaranteed when the green colour seal (KH … P5008) is installed on the oil side of the piston and the red colour seal (KG … P5010) on the gas side. The general recommendations as shown in our hydraulics brochure are applicable to the housing groove and seal installation, e. g. no sharp edges, no sharp tools, clean components, etc.
![]() |
SPGW-60 Piston Seals Higher Toughness Images |
